Flat Printed Electronic Circuit Board Dome LED Switch
Product Type: Membrane Switch with LED
Manufacturing: Silk Screen Printing
Durability: Over 1 million life cycles
Finish: Perfect exterior design
Product Specifications
Electrical Specifications
Wire Lead Resistance: <1Ω/CM
Rated Current: 25-100mA, 0-30V DC
Rated Voltage: <50V DC
Insulation Resistance: <100MΩ, 250V DC
Performance Specifications
Life Time: >1 Million cycles
Operation Temperature: -40°C to 70°C (-104°F to 158°F)
Operation Humidity: at 40°C, <98% RH
Dome Springback Time: <5 msec
Mechanical Specifications
Switch Travel (Flat Type): 0.05-0.3mm
Switch Travel (Tactile Type): 0.3-1.5mm
Base Material Voltage Withstand: 1500 V DC
Tail Flexibility: Any angle within 180 degrees
Materials & Construction
Primary Material: PET / PC
Adhesive: 3M467 & 3M468 or as per request
Certifications: ISO9001:2008, SGS, RoHS compliant
Applications
- Medical Equipment
- Telecommunications Apparatus
- Telephone Systems
- Household Appliances
- Security Systems
- Industrial Controls
Commercial Terms
Minimum Order Quantity: 150 pieces
Payment Terms: T/T or L/C
Mold Charge: 100% in Advance
Sample Time: 9-10 days after drawing approval
Production Lead Time: 15-22 days after sample approval
Manufacturing Details
Place of Origin: Dong Guan, China
Brand Name: Foundation
Model Number: HC-MS-007
